DOOSAN VT1100 CNC Vertical Lathe
- Storage Number
- 26019-875
- Machine type
- Vertical Lathes
- Manufacturer
- DOOSAN
- Type
- VT1100
- Year of construction
- 2007
- Location
- Langenfeld, Germany
- Documents
- Price
- This item is sold
- Control
- Fanuc Series 21i TB
- Dimensions (LxWxH) approx.
- 4200 x 3200 x 4500 mm
- Spindle speed
- ≥ 3000 rpm
- Turning diameter max.
- 1,000 mm
- Weight approx.
- 22,000 kg
The Doosan Puma VT1100 is a powerful CNC vertical turning center designed for the economical machining of large workpieces. Its stable machine construction with a vertical main spindle ensures high process reliability and optimal chip removal. The machine is suitable for machining flanges, rings, housings, and other heavy, rotationally symmetrical components.
The working area includes a maximum turning diameter of 1,100 mm, a maximum turning height of approximately 1,000 mm, and a maximum workpiece weight of approximately 2,000 kg.
Spindle: Vertical main spindle, spindle motor 45 kW, hydraulic chuck, hydraulic workpiece clamping, 12-position tool turret
Travel paths: X-axis approximately 650 mm, Z-axis approximately 800 mm
Workpiece data: Max. workpiece diameter: 1,100 mm, max. workpiece height: approximately 1,000 mm, max. workpiece weight: approximately 2,000 kg.
Equipment: hydraulic chuck, automatic central lubrication, coolant system, chip conveyor
- Machine light
- Electronic handwheel
- Installation area: approximately 5,000 x 4,200 mm
- Electrical data: connected load 90 kVA, max. power 45 kW
- Hydraulic chuck
- Chip conveyor
- Coolant system
- Transportation costs
- not included
- Terms of delivery
- EXW EX Works
- Terms of payment
- 100% prepayment before pick-up
The price of a used lathe depends on the machine type, swing diameter and distance between centres, control, year of manufacture, operating hours, included accessories such as chucks, steady rests or a bar feeder, and its condition. Transportation costs are not included in the machine price; terms of delivery and payment are stated under "Additional information" in each listing. You should also budget for installation and commissioning at the new site. In most cases, the buyer is responsible for organizing the transport; upon request, ReMach can check whether transport can be arranged or supported. ReMach also helps with dismantling, loading and export paperwork.
Three dimensions decide first: the largest workpiece diameter must be smaller than the swing diameter, the workpiece length must fit within the distance between centres, and for bar work the bar capacity stated in the listing must be at least the bar diameter. For hard materials and heavy cuts, the spindle also needs sufficient power and torque.
Yes, a turn-mill centre can mill, drill and cut slots in the same set-up as turning. Driven tools do the milling, the C-axis positions the workpiece, and a Y-axis allows machining off the centre line. A lathe without driven tools can only mill with an add-on attachment, with limited rigidity and output.
The difference lies in how the machine is controlled and which parts it suits. A cycle-controlled lathe is operated manually with stored cycles and teach-in, ideal for single parts and small batches, while a CNC lathe runs fully under program control for series production. A turn-mill centre adds driven tools and a C-axis, often a Y-axis, so turning, milling and drilling happen in one set-up. A vertical lathe holds the workpiece on a rotating table and suits heavy, large-diameter, low-height parts such as rings, flanges and discs.
A lathe is a machine tool for rotationally symmetrical parts: the workpiece rotates while the cutting tool moves along or across its axis. It is used for external and internal turning, facing, thread cutting, and drilling or boring on the axis. Typical parts are shafts, bushes, flanges, rings and threaded components.
