ALZMETALL GS1000 5-Axis Universal Milling Machine
Offer details
- Storage Number
- 26007-30
- Machine type
- Universal Milling Machines
- Manufacturer
- ALZMETALL
- Type
- GS1000
- Year of construction
- 2013
- Location
- Laichingen, Germany
- Price
- On Request
Technical details
- 5-axis machining
- yes
- Control
- Heidenhain iTNC 530
- Dimensions (LxWxH) approx.
- 4000 x 2250 x 2810 mm
- Dimensions of the clamping surface
- 800 x 630 mm
- Movement A-axis
- ≤ 140 °
- Movement C-axis
- ≥ 360 °
- NC rotary table
- yes
- Number of tool locations
- 33
- Spindle performance
- 29 kW
- Spindle speed
- ≥ 12000 rpm
- Travel X-axis
- ≥ 800 mm
- Travel Y-axis
- ≥ 800 mm
- Travel Z-axis
- ≥ 600 mm
- Weight approx.
- 15,500 kg
Description
ALZMETALL GS 1000/5-T CNC 5-axis machining center stable gantry design equipped with NC rotary tilting table and torque motors for backlash-free and highly dynamic direct drives in A and C axis simultaneous 5-axis machining possible equipped with 3D interpolation look-ahead TCPM and free contour programming water-cooled high-frequency motor spindle with thermal compensation (Therm-Ex) and air blow through spindle high-pressure coolant system extensive coolant equipment with band filter high-pressure pump and chip conveyor oil mist extraction system (LTA) integrated measuring systems with 3D probe (M&H) and laser tool measurement (Blum) collision monitoring (DCM) pick-up tool changer system automatic central lubrication LED working area lighting full enclosure
